NEWS
-
Atiatec's De-Embedding solution will demo in DesignCon 2018
We would like to invite you for visiting Ataitec in DesignCon 2018. For more informatin, please see the below.
You are cordially invited to visit AtaiTec at DesignCon Booth #600 to see how to use In-Situ De-embedding (ISD), Advanced SI Design Kit (ADK) and Material Property Extractor (MPX) to:- Perform causal and skewless de-embedding
- Extract spikes-free PCB trace attenuation
- Compare ISD and Delta-L results
- Correlate DUT results between measurement and simulation
- Process S parameters and run channel simulation
- Extract PCB material property (DK, DF and roughness)
- And more
- "In-Situ De-embedding" by C.C. Huang (AtaiTec) and D. Lin (Nvidia), 01/31/2018 (Wed), 9:20am – 10:00am, Great America Meeting Room 2.
and follow these papers we co-authored:- "Hacking skew measurement," 01/31/2018 (Wed), 2:50pm – 3:30pm, Ballroom E.
- "A NIST traceable PCB kit for evaluating the accuracy of de-embedding algorithms and corresponding metrics," 02/01/2018 (Thu), 11:00 am – 11:45 am, Ballroom G.
-
Ethernity Networks Demonstrates -- The Carrier Grade Switch and Traffic Aggregation Platform Running on COTS Servers in MWC2018Dear Sirs :
We would like to invite you to visit Ethernity Networks at MWC 2018.
At MWC 2018, Ethernity Networks Demonstrates -- The Carrier Grade Switch and Traffic Aggregation Platform Running on COTS Servers
Press Here to arrange the Live Demo!
Ethernity’s patented ENET technology resolves the challenges of carrier-grade performance in virtualized networks.
An architecture that attaches one or more All Programmable ACE-NICs via PCIe to a COTS server allows the integration of Carrier Ethernet MEF-compliant networking and routing, security and tunnelling offload into modern virtualized software platforms. The architecture provides a scalable data path up to 240Gbps and carrier-grade IP traffic aggregation, SLA support, OAM, routing, multi-protocol interworking, and security.
The solution is based on Ethernity’s All Programmable Intelligent NIC, equipped with a single FPGA performing the Carrier Ethernet networking functions and merging those functions with virtual networking functions running on the same server .
By merging the Carrier Ethernet functions with routing, tunnelling and security offload, Ethernity supports the trends associated with moving the cloud to the aggregation point.
Ethernity’s solution allows to utilise deployed servers as Ethernet aggregation platforms in conjunction with high performance vRouter, vBRAS, and vFirewall.
At Ethernity, we resolve performance, security, latency, and power consumption issues to provide the best of both telecom worlds: virtualized and traditional with guaranteed QoE.
-
CGS Tower Networks Demos the Network Visibility Solution in MWC2018Dear Sir :
We would like to invite you to visit CGS Tower Networking in MWC2018. If you will be there and would like to have a meeting with us, you are welcome to contact us for the meeting arrangement. We look forward to see you there.
CGS Tower Networks provides superior next generation network visibility solutions that enable and empower Cyber Security, Big Data Analytics and monitoring tools while reducing costs and complexity. We optimizes the tools layer by providing them with full network visibility and eliminating network bottlenecks in order to ensure maximum performance and benefits.
-
RAD's vCPE at the Customer Edge for Service ProvidersRAD, the industry pioneer of network edge virtualization, provides flexible vCPE platforms for the customer edge to fit diverse deployment scenarios. RAD offers a complete solution that includes L2/L3 NIDs featuring a virtualization engine, physical CPE (pCPE) devices, enhanced white box (Whitebox+) offerings, a powerful operating system (vCPE-OS) pre-integrated into RAD devices and available for third-party white box platforms, pluggable devices to accelerate server performance, and management and orchestration for the network edge.
This solution is complemented by RAD’s D-NFV Alliance, an ecosystem of network orchestrator and VNF vendors, as well as international system integrators specializing in new pre-certified NFV/vCPE applications.
For more info, please feel free to contact us. -
Ataitec introduces In Situ De-Embedding (ISD)If you ever need to do TRL calibration, you will find AtaiTec’s patent-pending In Situ De-embedding (ISD) technique most useful. Compared to more than seven test coupons on a TRL calibration board, ISD needs only one through trace. TRL requires that the calibration board and DUT test fixture have identical characteristic impedance, which is an impossible feat to achieve. In addition, TRL does not remove coupling among lead-in traces. The result is that the S parameters of DUT after TRL calibration are almost always non-causal and are difficult to correlate with simulation. ISD addresses all of these issues with a very simple procedure: (a) measure the through trace test coupon (which only needs to have similar, but not identical, behavior as the DUT test fixture); (b) measure DUT + test fixture; and (c) run ISD software.
If you are interested for this Software solution, please feel free to contact us. -
Eoptolink Sampling Industry 1st 200G 2×CWDM4 QSFP-DD Optical Transceiver
Eoptolink Sampling Industry 1st 200G 2×CWDM4 QSFP-DD Optical Transceiver
EOPTOLINK Technology Inc., Ltd (stock code: 300502.SZ) has announced the industry first 200G CWDM4 QSFP-DD optical module during CIOE 2017 and will do live demo in ECOC 2017. Eoptolink has been working closely with leading network and data-center solution providers and start sampling to customers.QSFP-DD 2x100G CWDM4 is using 8x25G NRZ DML technology, has doubled density of QSFP28, and fully complies with QSFP-DD and CWDM4 MSA. It targets data center for 2km application, and 10km version (2x4WDM-10) is also available. By using CS optical connector, it can be either two QSFP28 CWDM4 break-out or directly connected with another 200G QSFP-DD. The design can be easily moved to other form factor as well, for example OSFP.
This product is produced by Eoptolink 100G+ production platform with high density capability and automation. The platform is designed for high volume and low cost production for today’s 100G product and highly scalable for the coming 200G & 400G transceivers.
It adds to the portfolio of Eoptolink data center product line. Combining this product with QSFP28 CWDM4/CLR4, QSFP28 LR4 and QSFP28 4WDM-10, Eoptolink will provide up to date solutions to customers and continuously invest on R&D for new technologies.
-
Ag5324 - Industrial Temperature POE+ Module 24V output SIL POE+ Module
Ag5324 - Industrial Temperature POE+ Module
24V output SIL POE+ Module - Now Released
Following numerous customer requests Ag5324 has been designed as a low cost, smaller footprint replacement for the larger Ag5100 when used for 24V applications. It will allow customers requiring 24V at POE+ power levels to take advantage of the worlds smallest POE+ SIL package and footprint of the Ag5300 module. A further enhancement means Ag5324 is available as standard at industrial operating temperature specifications for operation between -40°C up to +85° Celcius. -
Silvertel - Ag7200, 20W Isolated DC-DC Boost Converter
Ag7200 - 20W Isolated DC-DC Boost Converter
The Ag7200 module is a low noise DCDC boost converter designed to generate the voltages required wherever an isolated 48V supply needs to be provided from a lower voltage e.g. for IEEE802.3 PSE, telecom or automotive applications. These modules provide exceptional efficiency (>90%) while providing full compatibility with the IEEE 802.3af power and isolation requirements and all in a low cost, compact SIL footprint package. With minimal extra components needed, circuit design is straightforward.
The module accepts a wide DC voltage input range, from 4.5V to 13V, providing added versatility. These input voltages are then boosted to generate the higher voltages required, for example, powering Silvertels’ Ag6100 or other compatible PSE circuits. Continuous power of up to 17W can be supplied, with a peak power capability of up to 20W. Ag7200 provides a regulated low ripple adjustable output, of either 48V or 57V.
The module uses a transformer to provide the necessary 1.5kV isolation between input and output connections to meet the requisite IEEE PoE safety and isolation requirements.
Ag7200 has been designed to provide an ideal solution for powering the Silvertel Ag6100 in POE 802.3af applications from a 5V on board supply, vehicle battery, 12V plug-top PSU or other commonly available power source. Its low cost, wide input voltage range, very small footprint, high efficiency and in-built isolation make it an extremely versatile DC-DC boost converter for a wide range of potential applications.The datasheet for this module is now released. Contact us for more info.
-
Silvertel - Ag104, Battery charge controller with MPPT
Ag104 - Miniature Battery Charger Module for low power and ambient light
The Ag104 is an intelligent, programmable, cost effective battery charge controller. Ag104 is designed specifically to harvest the energy available in low and ambient light conditions with low power solar cells to charge small batteries or Supercaps. It provides a comprehensive low power solution, designed to harvest and maximise the energy available, for charging a connected battery. Efficiency is optimised through the use of Maximum Power Point Tracking (MPPT) and programmable charging profiles. Intelligent charging monitors battery status, providing charging current or no charge, as necessary. Ag104 incorporates a Buck-Boost topology DCDC converter meaning it can accept a wide 1.8V to 25V input DC voltage range for added versatility, and can be used with a range of solar cells and battery capacities, dependent on the charge times expected or required.
It provides a drop in solution requiring minimal additional components for charging small batteries from solar cells.
It is low cost and high efficiency in a very small footprint while its intelligent charging features make it extremely versatile for use in modern Eco-friendly solar cell powered, battery backed electronics installations, such as room sensors, lighting controls, alarm systems and access control.The datasheet for this module is now released. Contact us for more info.
