NEWS
-
[LIPS] LIPS 3D sensor solution invitation in MWC2019LIPS Corporation : Booth location : Hall 4YFN Montjuic Hall M8 Stand 7 (map) in different location
LIPS are positioned as 3D Machine Vision Platform provider offering:- 3D depth cameras based on ToF, Structured Light, and Active Stereo technologies; standard recognition middleware; standard solutions.
- LIPS not only design, build, and customize 3D depth cameras but also create various recognition middleware and solutions to fulfill your applications.
- Besides we do customize camera design, middleware, and total solution projects for developers and marketers worldwide.
-
[RAD] RAD solution invitation in MWC2019RAD : Booth number : 5E41
Come to discover RAD’s latest innovations:- Award Winning Service Assured vCPE Toolbox – see why tier-1 CSP are choosing our comprehensive, open vCPE solution for all use cases.
- Industrial IoT with Edge Computing – discover our unique end-to-end solution to reduce the number of devices in the network while increasing reliability and security.
- Learn how to make your xHaul 5g-ready – with rates up to 100G, end-to-end slicing support, ultra-low latency, and service and network orchestration.
-
[Ethernity] Ethernity SmartNIC solution invitation in MWC2019Ethernity : Booth number : Hall 2 IMA booth
- The new ENET VPN Gateway with its unique Host Bypass feature for enhanced cyber security
- Our 100G ACE-NIC100 SmartNIC for networking/security offload and VNF acceleration
- Ethernity’s new vRouter network appliance
-
[RunEL] RunEL 5G solution invitation in MWC2019RunEL : Booth number : 5E41-9
- Demo 5G Distributed Architecture (DRAN + RRH) with 2x200MHz BW
-
[RunEL] The SPARQ-2020 Chipset Series for 5G applications
RunEL's Sparq-2020 System on Chip (SoC) offers unbeatable performance for Ultra Reliable Low Latency (URLLC) applications such as V2X, Connected Cars, Drones Communication, Remote Surgery, Interactive Games, etc.
The Sparq-2020 is 5G 3GPP standard compliant (REL-15) and is optimized for URLLC applications in order to deliver unbeatable latency below (250 microseconds) using its unique "Sparq Minislots" and "Integrated Mobile Edge Computing" (I-MEC) technology.
The Sparq-2020 is used in 5G New Radio (NR), Remote Radio Head (RRH) and Smart RRH (SRRH) type of Products.RunEL also provides the Sparq-2020 Reference Design Board (RDB) to enable equipment manufacturers an easy and painless process from design to commercial product at different 5G bands (mmWaves below 6GHz and other bands.
-
[SilverTel] IEEE 802.3bt – The New 4 pair Standard of PoE
Current Standards
Since its first release, in 2003, it became obvious that PoE provided great benefits however some applications were restricted by the power available. The first specification, called IEEE802.3af, allowed up to 12.95W at the Powered Device (PD) and the second, released in 2009 and called IEEE802.3af, allowed up to 25.5W. This allowed for 100m of cable between the Power Sourcing equipment (PSE) and the PD. The power could be supplied on the spare pair or the data pair which was referred to as Mode A or B.
Standard Power from PSE
(W)Power a
PDCable Type Mode 802.3af 15.4 12.95 Cat 3 or 5 A or B 802.3at 30 25.5 Cat 5 A or B It is important to note that the standards are backwards compatible i.e. an 802.3af PD can be used with an 802.3at PSE and an 802.3at PD can be used with an 802.3af PSE but with the power limited by what the PSE can supply.
PoE can also be defined by the Type where a Type 1 is an IEEE802.3af device and Type 2 is IEEE802.at device. Within each Type there are various classes that the PD presents to the PSE which defines the minimum power delivered to the PD and would allow the PSE to manage its power available.
PoEType Class Current(mA) PD per Pair (W) PSE Power Per Pair (W) 1 0 0 - 4 0.44 - 12.94 15.4 1 1 9 - 12 0.44 - 3.84 4 1 2 17 - 20 3.84 - 6.49 7 1 3 26 - 30 6.49 - 12.95 15.4 2 4 36 - 44 12.95 - 25.50 30 What 802.3bt brings
More Power - This new standard allows the transfer of at least 71W to the PD with the maximum cable length. This extra power is delivered across all four pairs which minimizes the losses in the cable. This extra power available allows more applications at higher power like smart LED lighting, Cameras with AI and larger digital displays. However with this higher power and faster data speeds, cable quality and electronic design now becomes an important factor when trying to achieve maximum power and error free data transmission.
Connected Devices -The new standard allows for this higher total power to be split across two separate PD devices from a single IEEE802.3bt PSE output. The PSE will check both pair sets to see if it’s connected to single or dual signature PD. A single signature PD connection will operate as you would expect, monitoring the overall power consumption and imbalance between pair sets. A dual signature connection allows the designer to have two individual PD devices within their system, monitored by a single IEEE802.3bt PSE, thus giving them the opportunity for 2 independent rails within their system whilst only using a single Cat5e cable. The independent monitoring on each pair set also allows for power saving in the end users device where one of the rails may choose to go into standby mode whilst the other rail may need to continue to operate at full power.
New classes and types - The increase of power is not implemented in one step the standard brings 2 new PoE types and 4 new classes for effective power management.
PoEType Class Current(mA) PD per Pair (W) PSE Power Per Pair (W) 3 4 0 - 4 12.95 - 25.5 30 3 5 9 - 12 40 45 3 6 17 - 20 51 60 4 7 26 - 30 62 75 4 8 36 - 44 71 90 Lower standby power –After powering the port the PSE monitors the current drawn is above a set limit, known as the Maintain Power Signature (MPS), to detect if the PD has been disconnected. The IEEE802.3bt is more energy conscious and has improved its MPS to allow a lower stand by power which is ideal to meet today’s needs.
In order to keep the port active, an IEEE802.3af or IEEE802.3at PD must draw approximately 10mA or a duty cycle of 30% from the PSE. With most systems, we would expect to see about 150mW of loss per port, so if we had multiple lighting systems on multiple ports, for example 10, this would equate to 1.5W of lost power when unit in standby. The new standard has changed this and now the PSE will only require a very conservative duty cycle of ~2%. This reduces the amount of power lost per port by a factor of 15. This is beneficial where devices can be put into sleep mode i.e. PoE lighting systems or security systems that may only be needed to be active during night time and turned off during the day.
Automatic Classification -Auto classification is a new system in which the PSE can automatically detect the actual maximum power drawn by the PD. The PSE will measure the maximum power drawn by the PD over a set amount of time and then assign this power to that port plus some margin.
Backwards Compatibility -As with 802.3at, the 802.3bt standard will be fully backwards compatible with the previous standards of PoE. This system, in theory, should work automatically with any PD (As long as the PSE has the means to supply the required power). In the scenario where an 802.3bt PD is plugged into a lower standard PSE, the device may turn on if the power consumed is within the PSE power limitations, but will fail to start or shutdown if its power is much greater than the PSE’s power capability.
802.3bt Applications
* LED Lighting * Industrial PCs * Automated Teller Machine (ATM) * LED displays * POS terminals * IoT access points * Automated Teller Machine (ATM) * Smart IP Cameras * Automation Control Systems Considerations – When using higher power applications
As with every product produced, there must be considerations made. As the new standard is released and we start to see an influx of new designs, it is important to consider the thermal requirements of the PD. In this new age of technology, size is everything. Products and devices are getting smaller and slimmer, as such it is important to monitor and rectify the thermal implications of high power designs. Heatsinks and thermal management are a must and are more important than ever. With the amount of power almost tripling, internal temperatures of devices will rise much quicker. PD placing within the enclosure becomes a vital factor in being able to operate the device at its maximum operating power, such that maximum airflow and heatsinking can be achieved.
Summary
In conclusion 802.3bt, will bring a whole new avenue of opportunity to the world of PoE. Introducing new ways to improve LED lighting, smart homes and other connected devices. We will see new and more advanced security systems taking advantage of the new power limit. As the world continues to evolve and we develop more energy efficient devices, the list of applications for PoE will only increase.
Silvertel’s range of PoE modules will make the transition into the new standard easier than ever. With our 802.3bt compliant modules, implementation of 4 Pair PoE technology into your device will be seamless, easy and cost effective. They provide the complete solution using minimal external components.
Ag6800 - IEEE802.3bt PSE Ag5800 - IEEE802.3bt PD (12/24V output) -
[NVE] NVE Introduces Low Power Isolators -- IL01x SeriesWith the addition of the two-channel and four-channel one-direction versions, low-power TMR isolators are now available in the all the popular channel configurations.
Typical IL01x-Series total quiescent current is just 0.3 mA per channel, one-fourth the power of our flagship products.
The new devices use NVE’s patented low-power spintronic Tunneling Magnetoresistance (TMR) technology.
A unique ceramic/polymer composite barrier provides excellent isolation, best-in-class barrier resistance, and virtually unlimited barrier life.
The new parts are low power and provide remarkable performance:
• 10 Mbps guaranteed maximum data rate
• No carriers or clocks for low EMI
• 100 teraohm insulation resistance
• 2.5 kV isolation
• 44000 year barrier life
• -40°C to +100°C
The four-channel versions use NVE’s unique True 8™ wide-body SOIC-16 package with full 8-millimeter creepage in accordance with IEC60601.
Applications include:
• 4-20 mA loop-powered controls
• Battery-powered instruments
• SPI
-
[MITS] MITS introduces 200GBASE-SR4 QSFP56 Active Optical CableDue to the 200G request is more and more important for high speed interconnect application, especially in Data Center. And the AOC cable sgoud take an important role for this area, so MITS just introduce the 200GBASE-SR4 QSFP56 Active Optical Cable, AOC-200G-Q56/Q56-3-xx series. (xx: cable length, meter)
The below is more product info for your reference.
Features :- Hot Pluggable QSFP-DD Cable End
- Supports 212.5Gb/s aggregate bit rate
- Low Power Dissipation, Typ. 5.0W Each End
- 4x50G PAM4 VCSEL/PIN photo detector
- Operating Case Temperature: 0℃~70℃
- SFF-8636 Management Interface
- SFF-8679: General Electrical
- IEEE 802.3cd: Physical Layer Specifications and Management Parameters
- ROHS-6: Environment Safety
If you have any question or need, please feel free to contat us.
-
[SilverTel] Ag9900 Series - Ultra-miniature IEEE802.3af POE (Product Update)
Ag9900 Series - Ultra-miniature POE (IEEE802.3af)
Ag9900 is now the smallest PoE module in the world, superseding the Ag9800. The three versions Offered:- M - standard IEEE802.3af compliant surface mount module; MT – standard + Industrial temperature surface mount module; LP – same PoE standard with Low profile (less than 8mm high). It is designed such that adding just two diode bridges and an electrolytic capacitor to this truly tiny module is enough to enable PoE functionality in a product. Ag9900 is fully compliant to the IEEE 802.3af PoE standard. It provides a POE signature, classification, isolation and DC to DC conversion options for 12V, 5V, 24V or 3.3V, while taking up minimal PCB space. It is ideal for space constrained PoE applications such as IP phones, wall mount appliances, IP cameras, thermostats, smoke detectors and room sensors, and is perfect for a whole range of new IoT and building automation sensors and devices.
Key Features :- Ultra-miniature package size and profile
- Cost optimised IEEE802.3af POE
- Overload and short-circuit protection
- 1500V DC impulse test isolation (input to output)
- Integral DC/DC converter
- Integrated Thermal Protection option
