AtaiTec Corporation was founded to help high-speed designers efficiently perform their daily SI tasks
1.2D/3D field solver simulation
2.Circuit simulation
3.Channel simulation
4.VNA/TDR measurements
5.Correlation and ...etc.
What We Do
We specialize in signal and power integrity modeling, simulation, and measurement correlation for IC, package, connector, cable, and board. Our mobile-apps-like SI software together complements your 3D full-wave field solver, circuit simulator and VNA, and helps you correlate simulation and measurement results:
- ISD (or in Situ De-embedding) is meant to replace TRL calibration and help save SMAs and board material.
- ADK (or Advanced SI Design Kits) is a collection of many commonly used SI utilities that provide a one-stop solution for your SI analysis needs.
- X2D2 is an ultra accurate 2D RLGC field solver with surface roughness model to help you define the PCB stackup and trace width/spacing for impedance control and desired insertion loss.
- MPX (or Material Property Extractor) automates de-embedding, PCB material property extraction and report generation into just one mouse click.
Why We are Unique
We need to know the fundamentals and limitations of :
- Boundary element method (BEM),
- Finite element method (FEM),
- Modified nodal analysis (MNA),
- Calibration methods (SOLT, TRL, unknown thru), etc.
To Solve :
- How do you set up models, excitation, and boundary conditions for 3D full-wave solvers?
- How much error are you getting from the simulation or measurement data?
The major benefits with Ataitec Signal Integrity SW
- Great ROI : Want to know how you can save SMAs, board material, and time in VNA measurements? Just try our In Situ De-Embedding (ISD)
- Free Trial : Just send us two Touchstone files — one for through trace and one for DUT + test fixture — and we will send you the extracted DUT Touchstone file.
