100G QSFP28 Optical Transceivers

1. 100 QSFP28 Optical Transceivers :

Eoptolink’s 100G QSFP28 series transceivers include SR4, CWDM4, CLR4, LR4, ELR4, ER4 Lite and ER4 modules. They are designed for use in both 103G Ethernet and OTU4 links over 100m MM fiber, 2Km, 10km, 20km, 25km and 40km SM fiber. Digital diagnostics functions are available via the I2C interface and all the modules are compliant with the IEEE 802.3ba and SFF-8636 MSA.


Features :

  • Supports 103.1Gbps aggregate bit rates
  • Single 3.3V Power Supply and Low Power dissipation
  • Up to 100m transmission on MMF OM4 and 10km/2km over SMF.
  • Hot-Pluggable QSFP Footprint
  • Class 1 FDA and IEC60825-1 Laser Safety Compliant
  • RoHS6 Compliant
  • Operating Case Temperature Standard: -5~+75C
  • Compliant with QSFP MSA Specification
  • I2C interface with integrated Digital Diagnostic Monitoring
  • 4x25G electrical interface

Applications :

  • High-speed interconnects within and between switches, routers and transport equipment
  • Server-Server Clusters, Super-computing interconnections
  • Proprietary backplanes
  • Interconnects rack-to-rack, shelf-to-shelf, board-to-board, board-to-optical backplane
  • 100GBASE-LR4 Ethernet links
  • 100GBASE-SR4 applications
  • 100GBASE-LR4 Lite 2km applications
  • OUT4
  • 100GBASE-SR4/CWDM4/LR4/ … Ethernet links


Ordering info. :

P/N Type Distance Laser Data Rate Fiber Port T.range
EOLQ-851HG-02-MO QSFP28 SR4 100m VCSEL 103Gbps MM MPO 0~70°C
EOLQ-851HG-02-MOY QSFP28 SR4 100m VCSEL 103/112Gbps MM MPO 0~70°C
EOLQ-161HG-02 QSFP28 CWDM4 CLR4 2km DML 103Gbps SM 2xLC 0~70°C
EOLQ-161HG-02-B QSFP28 CWDM4 CLR4 2km DML 103/112Gbps SM 2xLC 0~70°C
EOLQ-161HG-10-L  QSFP28 LR4 10km DML 103Gbps SM 2xLC 0~70°C
EOLQ-161HG-10-LA QSFP28 LR4 10km EML 103/112Gbps SM 2xLC 0~70°C　
EOLQ-161HG-10-LB QSFP28 LR4 10km DML 103/112Gbps SM 2xLC 0~70°C





2. 100 QSFP28 Active Optical Cables


Eoptolink QSFP28 Active Optical Cable is a 4-channel optical transceiver, which conforms to QSFP28 MSA and works at the rage of 25Gbps per channel. The AOC conforms to transmission speed required by InfiniBand™ EDR, 100 Gigabit Ethernet (100GBASE-SR4) and enables to transmit maximum 100m. Best for close-range high-speed transmission, for example, between server racks, between servers.

Features :
  • Compliant to the IEEE 802.3bm(100GBASE-SR4)
  • Compliant to the SFF-8665 Specification
  • Active Optical Cables Length up to 70m
  • VCSEL array transmitter and PIN array receiver
  • Low Power dissipation <3.5W
  • Operating Case Temperature: 0℃~+70℃

Application :

  • 100G BASE SR4 Ethernet interconnects

Ordering info. :

Part No. Type AOC Length  Data Rate Fiber Temp.
EOLQ-851HG-PCT-XX QSFP28 AOC 1~100m 103Gbps MM 0~70°C
EOLQ-1HG-PCT-XX-8 QSFP28 to 4*SFP28 AOC 1~100m 103Gbps MM 0~70°C
 *Length measured OM3 fiber. XX denotes the AOC length with unit meter. For example, 01 denotes 1m, 02 denote 2m … 100m(OM4).
