Product Description
Part number: WOB-2458AC
| HARDWARE | |
| LAN | 1 x 10/100/1000 BaseT RJ-45 with Auto-MDIX |
| Power Over Ethernet (PoE) | Yes (802.3af/at) |
| Default Button | Yes |
| Enclosure | Plastic PC Case, IP 67 / 68 Verified |
| Lighting Protect | Yes |
| Ground | Yes |
| LED | Power / RSSI / LAN |
| RADIO | |
| Frequency | 2.4 / 5 GHz |
| Standard | IEEE 802.11 a/b/g/n/ac |
| Wireless | OFDM |
| Output Power | 28 dBm @ 2.4GHz / 26 dBm @ 5GHz |
| Sensitivity | -92 dBm @ 2.4GHz / -90 dBm @ 5GHz |
| Antenna | WOB-2458AC-I Build-in 5GHz 2x2 23 dBi WOB-2458AC 4 N Connectors |
| FEATURES | |
| Operating Mode | AP, Bridge, CPE, Repeater |
| Channel Bandwidth | 20 / 40 / 80 MHz |
| Data Bandwidth Control | Yes |
| Output Power Management | Yes (Full, Half, Quarter, Eighth, Min.) |
| DFS | Yes |
| NAT | Yes |
| DHCP | Server / Client |
| VLAN | Yes |
| Spanning Tree | Yes (802.1d) |
| RTS Threshold Setting | Yes (0-2,346) |
| Fragmentation Setting | Yes (256-2,346) |
| Beacon Interval Setting | Yes (20-1,000) |
| DTIM Interval Setting | Yes (1-255) |
| SECURITY | |
| MAC Control | Yes |
| WEP Encryption | 64, 128, 152-bit |
| WPA / WPA2 | Yes |
| Wireless Isolation | Yes |
| Hidden SSID | Yes |
| Firewall | Yes |
| VPN | VPN Pass-through (IPsec, L2TP, PPTP) |
| MANAGEMENT | |
| Web Base Management | Yes |
| NMS | Yes (WiVIEW 2) |
| SNMP | V1, V2C, V3 |
| Support Time Server | Yes |
| Support Log Server | Yes |
| PHYSICAL | |
| Operating Temperature | -30 ~ 80C |
| Humidity | 0 ~ 90% RH |
| Model | Frequency MHz | Antenna dBi | Output Power dBm | Sensitivity dBm | Dimension mm | Weight Kg |
| WOB-2458AC | 2.4 / 5 GHz | 5GHz 2 N Jack 2.4GHz 2 N Jack |
28 dBm @ 2.4GHz 26 dBm @ 5GHz |
-92dBm@2.4GHz -90dBm@5GHz |
259 x 250 x 75 | 1.8 |
