Product DescriptionPart number: WMB-2400-2
| HARDWARE | |
| CPU / Memory | Atheros AR7161 680MHz / 16MB Flash + 64MB SDRAM |
| LAN | 1 x 10/100/1000 Mbps RJ-45 with Auto-MDIX |
| Power Over Ethernet | Yes, 802.3at 48V DC 0.2A, w/ 4KV Lighting Protection / 15KV ESD Protection |
| Default button | Yes |
| PHYSICAL | |
| Antenna | 2 N Connectors |
| Frequency | 2.4GHz (Single RF) |
| Enclosure | Metal Enclosure, IP68 verified |
| Maximum Output Power | 23 dBm |
| Sensitivity | -92 dBm |
| Dimension | 259 × 250 × 75 mm |
| Weight | 1.8 Kg |
| ENVIRONMENT | |
| Operating Temperature | -20 ~ 75C |
| Storage Temperature | -20 ~ 80C |
| Storage Humidity | 5 ~ 95% RH |
| FEATURE | |
| Operation Modes | AP, MESH 802.11s |
| Link Test | Yes |
| WMM (AP Mode) | Yes |
| Radio Modes | Standard 802.11a/n Mode |
| Multi Mesh | Yes |
| Channel Bandwidth | 40/20/10/5MHz |
| Scheduled Tasks | Yes |
| SECURITY | |
| WEP Encryption | 64, 128 bit |
| WPA | WPA Enterprise/WPA-PSK |
| MESH | AuthSAE |
| MANAGEMENT | |
| Web Base Management | Yes |
| HTTP F/W Upgrade | Yes |
| SNMP | Yes, MIB2 |
| Windows Utility | Yes (WiVIEW 2) |
| Model | Frequency MHz | Antenna dBi | Output Power dBm | Sensitivity dBm | Dimension mm | Weight kg |
| WMB-2400-2 | 2.4GHz (Single RF) |
2 N Connectors | 23 dBm | -92 dBm |
259 × 250 × 75 | 1.8 |
Packaging & Shipping
Lead Time: 4~8 weeks
We ship whatever you ask, by DHL/UPS/FEDEX/EMS, air or ocean shipment.
Accept small, trial orders, and customised orders too!
Please note: All of our product's delivery term is:Ex-work Taiwan
If there is any product information needed, please contact us or consult online.
