Product Description
Part number:
VST-007T
Application
·       CCTV Surveillance installation and maintenance
·       Networking surveillance installation and maintenance
·       Speed Dome and IP CAM Testing
·       PING testing and IP address scan
·       PTZ protocol control and analysis
Model VST-007(VII generation)【T】is optional
Video Test
Signal mode NTSC/PAL (Auto adapt)
Display 3.5 inch digital TFT-LCD ,480(RGB)x 320 resolution
LCD adjustment Brightness, Contrast, Saturation adjustable
Video IN/OUT 1 channel BNC Input & 1 channel Output
Video Output Mode 1.0 Vp-p
Video Level test
Level test Video signals measured in IRE or mV
DC 12V 1A power output
DC 12V power output Output DC12V1A power for camera
Audio input test
Audio input test test the pickup and other audio equipments on the front-end
PTZ controller
Communication Support RS232 and RS485
PTZ Protocol Compatible with more than 30 protocols such as PELCO-D/P, Samsung, Panasonic, Lilin, Yaan, etc.
Baud Rate 600,1200,2400,4800,9600,19200,57600,115200bps
Video Signal Generation
Color bar generator Output one channel PAL/NTSC color bar video signal for testing monitor or video cable.(red, green ,blue, white and black color )
UTP Cable tester
UTP cable test Test UTP cable connection status and display in the screen. Read the number of the test box.
RS485 data analysis
Data Monitor Captures and analyzes the command data from controlling device
10x Zoom Image
Image 10x zoom 10x zoom image display and video out
Photograph、Video record, Record playback
Photograph snapshot and save the current image as JPG file
Video record Video record and storage the file
Record playback To view the storage file in the SD card
Port flicker
Port flicker Find the connected POE port quickly.
IP scan、Link monitor、PING test
IP scan Find out the connected IP camera or the other network equipment IP address quickly.
Link monitor Check the IP address whether is occupied
PING testing Test IP camera or Ethernet port of the other network equipment whether work normally, and check the IP address


Packaging & Shipping


Lead Time: 4~8 weeks
We ship whatever you ask, by DHL/UPS/FEDEX/EMSair or ocean shipment

Accept small, trial orders, and customised orders too!


Please note: All of our product's delivery term is: Ex-work Taiwan
If there is any product information needed, please contact us or consult online.
