Product Description
Part number: MLS-001
Application
· Optical Communication Engineering and maintenance
· CATV fiber optic Engineering and maintenance
· Researching Fiber Optic Sensing
· Passive Optical Network (PON)
| Model | MLS-001 |
| Emitter Type | FP-LD |
| Wavelength (nm) | 1310、1490、1550 （650 optional） |
| Optical Connector | FC（SC/ST optional） |
| Out power(dBm) | Typical value :-0.0dBm -6dBm optional |
| Power | Two No.5 Batteries |
| Fiber mode | SM、MM |
| Battery operating time (h) | 38 Hours |
| Operating temperature ℃) | -10～+60 |
| Storage temperature(℃) - | -25～+70 |
| Dimensions(mm) | 168×103×45 |
| Weight(g) | 300 |
