Product Description
Part number: MIT-612-56
Application
· IP Cameras
· Speed Dome
· Security CAM
· Door Security
RJ-45 Connector and Pin-out
| RJ-45 Input (Data Only) | RJ-45 Output (Data & Power) | |||
| Pin | Symbol | Description | Symbol | Description |
| 1 | Rx+ | Data Receive | Rx+ | Data Receive |
| 2 | Rx- | Data Receive | Rx- | Data Receive |
| 3 | Tx+ | Data Transmit | Tx+ | Data Transmit |
| 4 | Data | Data | +Vdc | Power(+)+Data |
| 5 | Data | Data | -Vdc_return(+) | Power(+)+Data |
| 6 | Tx- | Data Transmit | Tx- | Data Transmit |
| 7 | Data | Data | -V dc | Power(-)+Data |
| 8 | -V dc | Data | -V dc | Power(-)+Data |
Packaging & Shipping
Mechanical & Dimension
| Case Material | Metal |
| Case Color | Silver (Black) |
| Case Dimension | 431 x 220 x 70 (W x D x H) mm |
Lead Time: 4~8 weeks
We ship whatever you ask, by DHL/UPS/FEDEX/EMS, air or ocean shipment.
Accept small, trial orders, and customised orders too!
Please note: All of our product's delivery term is:Ex-work Taiwan
If there is any product information needed, please contact us or consult online.
