Product Description
Part number:

POE-GIE-3556IN4
Description:  DC 10V~15V Input, 35W/56V ouput, No optional function
Application
·         Industrial PC

·         Transportation
·         Security CAM
·         Any Gigabit Ethernet terminals which work with industrial DC input system
·         Any Gigabit Ethernet terminals which require power under 30W

  RJ-45 Input (Data Only) RJ-45 Output (Data & Power)
Pin Symbol Description Symbol Description
1 Rx+ Data Receive Rx+ Data Receive
2 Rx- Data Receive Rx- Data Receive
3 Tx+ Data Transmit Tx+ Data Transmit
4 Data Data +Vdc Power(+)+Data
5 Data Data +Vdc Power(+)+Data
6 Tx- Data Transmit Tx- Data Transmit
7 Data Data -Vdc Power(-)+Data
8 Data Data -Vdc Power(-)+Data

Packaging & Shipping

Mechanical & Dimension
Plastic Case Material PC
Plastic Case Finish Texture
Plastic Case Color Gray
Plastic Case Dimension 125 x 75 x 38 (L x W x H) mm.

Package
Number of unit in one Carton 50
Weight of Carton Volume N.W.:15Kg. G.W.:16Kg. 1.3Cuft.
White Box Dimension 165 x 82.5 x 44 (L x W x H) mm

Lead Time: 4~8 weeks
We ship whatever you ask, by DHL/UPS/FEDEX/EMSair or ocean shipment

Accept small, trial orders, and customised orders too!

Please note: All of our product's delivery term is:
Ex-work Taiwan
