Internally-clocked digital isolators...
Internal clocking ensures deterministic power-up, and outputs always follow the outputs (“DC correct”). In some versions the clock can be disabled for ultra-low power consumption. IL500-Series Isolators are a cost-effective alternative to digital optocouplers in a number of applications including serial interfaces, isolated Serial Peripheral Interface (SPI), isolated A/D converters, and isolated power interfaces.
Key features are:
 |
DC Correct 2 Mbps 10 ns PWD 1, 2, 3, or 4 Channels |
|
Low EM Emissions 30 kV/µs min. Transient Immunity 44000 Year Barrier Life MSOP and SOIC Packages |
