Product Description
Part number:
POE-GIJ-1818NNN
Description:  18W/18V output, No optional function
Application
·         IP Phone
·         IP Camera
·         Access Point
·         Door Security
·         Security CAM
·         Network terminals which require power under 24W
  RJ-45 Cable Output (Data Only) RJ-45 Socket Input (Data & Power)
Pin Symbol Description Symbol Description
1 Rx+ Data Receive Rx+ Data Receive
2 Rx- Data Receive Rx- Data Receive
3 Tx+ Data Transmit Tx+ Data Transmit
4 Data Data +Vdc Power(+) + Data
5 Data Data +Vdc Power(+) + Data
6 Tx- Data Transmit Tx- Data Transmit
7 Data Data -V dc Power(-) + Data
8 Data Data -V dc Power(-) + Data

Packaging & Shipping
Mechanical & Dimension
Plastic Case Material PC
Plastic Case Finish Texture
Plastic Case Color Gray
Plastic Case Dimension 86 x 78 x 36 (L x W x H) mm.
Package
Number of unit in one Carton 100
Weight and Volume without Power cord N.W.:17Kg. G.W.:18Kg. 1.9Cuft.
White Box Dimension 120 x 85 x 40 (L x W x H) mm
Power cord Package N.W.:15Kg. G.W.:16Kg. 1.3Cuft.




Lead Time: 4~8 weeks
We ship whatever you ask, by DHL/UPS/FEDEX/EMSair or ocean shipment

Accept small, trial orders, and customised orders too!


Please note: All of our product's delivery term is: Ex-work Taiwan
If there is any product information needed, please contact us or consult online
